Saturday, August 01, 2015

Monitoring Environment Ruang server di area remote

Salah satu tantangan untuk melakukan monitoring Environment ruang server yang letaknya jauh, terpencil, dan jarang didatangi. Seringkali ini tidak kita perhatikan, padahal yang sering terjadi, ruang server ini merupakan ruangan yang menampung koneksi / perangkat yang sangat penting, baik untuk koneksi ataupun lainnya.

Hal ini kami temukan dalam beberapa customer, dimana mereka memiliki ruang server yang letaknya di atas gedung, di area yang jarang sekali mereka datangi. Disinilah sangat pentingnya peranan Environment Monitoring System (EMS).

Selaku distributor AKCP, kami sering diminta pendapat mengenai hal ini. Oleh karena itu, saran kami diantaranya :

  1. Ruang server yang letaknya tidak mudah diakses / dijangkau, namun memiliki fungsi kritikal, maka ruang server seperti ini harus dilengkapi dengan EMS, baik dalam skala sederhana ataupun kompleks hingga sampai CCTV.
  2. Tidak harus menggunakan perangkat EMS yang kompleks, melainkan fokus kepada fungsi. Contoh, kami menemukan kasus dimana apabila perangkat yang didalamnya menjadi panas akibat AC mati, maka tentu yang harus dimonitor adalah suhu dan humidity di dalam ruangan / rak.
Maka dapat menggunakan solusi menggunakan perangkat AKCP SensorProbe, mulai dari SensorProbe 2 yang memiliki 2 port sensor.


SensorProbe series mengirimkan alert hanya melalui media email, sehingga harus disediakan router yang memungkinkan untuk mengirimkan alert email. Untuk koneksi ini, saya mengetes dengan menggunakan Hame Router dan Modem ZTE , sehingga koneksi 24 jam bisa didapat dengan cepat. Dengan berkembangnya dan semakin banyaknya router ukuran kecil, maka sangat mudah menyediakan koneksi ke Internet secara 24 jam.

Untuk SecurityProbe, maka disediakan langsung modul Modem 3G yang dipasang di dalam unit.


Internal 3G Modem
With this modem, your securityProbe unit can connect to the Internet using your local GSM, GPRS, EDGE or 3G service
This AKCP Internal 3G Modem is ideal for remote locations, where a securityProbe is being used to monitor and control critical environmental factors.


Silahkan kontak kami apabila ada kebutuhan terkait monitoring environment di remote area. Kami siap membantu.






Saturday, July 25, 2015

Analisa Paket untuk lindungi jaringan Anda

Analyse Packet Capture to Protect Your Network

network security
For a network administrator or someone in a production environment who gets paranoid about whether anybody is snooping on the network, tools such as tcpdump act as a reassurance, as they help to counter such threats. This article discusses the processing and analysis of packets that have been captured by tcpdump or Wireshark.
When it comes to network security, the first thing that people should be taking care of is their own network. This can be achieved by analysing your data and making sure that no one is intruding on your network. The name ‘PCAP’ comes from the two words, ‘packet capture’.  The type of file is the Ethernet packet sniffer, which means that this file format is used by the tools that analyse the network traffic. In this article, I will start with the basics so that even a newbie can easily analyse the data, using the tools mentioned.
The basics
Anyone who is new to network security needs to have a good grasp of the various types of networks. The basic types are TCP (Transmission Control Protocol) and IP (Internet Protocol). We do have many versions of IP and the address varies with the type. This understanding is necessary because, with the help of the IP address, we can determine the location of someone who is mounting an attack. I would suggest you visit some of the links below, which will be helpful to get an understanding of the basics of networking.
http://en.wikipedia.org/wiki/Network_security
http://cse.hcmut.edu.vn/~minhnguyen/NET/Computer%20Networks%20-%20A%20Tanenbaum%20-%205th%20edition.pdf
http://www.cert.org/historical/tech_tips/home_networks.cfm
The best way to get a strong foundation on the subject would be to Google for information, instead of just reading many books. It is better to concentrate on a single book and try out various tools to get a good command over them.
Tools
Many tools are available for the analysis of packets, the most basic and most powerful one being tcpdump. It can be installed or updated by using the following command:
sudo apt-get install tcpdump
Many open source tools are available to us but none match tcpdump. It is the best tool to capture and filter packets using a basic C code – something that I will discuss briefly, subsequently.
For Windows, there are many tools such as Wireshark and WinPcap. The links are given below.
http://www.winpcap.org/install/default.htm
http://wiki.wireshark.org/Tools
You can get a list of all the tools in open source from here.
http://www2.opensourceforensics.org/tools/network
Everything can be done in the terminal with the help of tcpdump. The remaining tools give us easy access, some benefits and some ready-made features.
1
Figure 1 : Installing tcpdump
Capturing one’s own data
It’s very easy to capture your data in Linux by using the terminal (Ctrl+Alt+T) and typing the following command:
sudo tcpdump -w capture.pcap
This command invokes the tool tcpdump and writes the data into the file name ‘capture.pcap’ (remember .pcap is the extension for the packets captured). This goes on until you give it a keyboard interrupt (Ctrl+C) or temporarily stop the job with Ctrl+Z. Packet capture can be resumed by giving the command fg which is the same as the normal command.
Packet capture can also be done by using online tools such as Wireshark.
Have a look at the man page of tcpdump before going ahead with the article.
man tcpdump
Analysis
I assume that you have a good knowledge of commands (such as ‘|’ and ‘*’) used in the terminal, for this section. If not, here are some links to tutorials that will teach you the basics.
http://linuxcommand.org/lc3_learning_the_shell.php
http://ss64.com/bash/
http://www.pas.rochester.edu/~pavone/particle-www/telescopes/ComputerCommands.htm
The best way to learn about them is to refer the man page when you have a doubt about a particular command.
Count of packets
To determine the count of packets in the file, we use the following command:
tcpdump -nn -r capture.pcap | wc -l
Since the file usually contains a large amount of data, instead of using the ‘cat’ command, it is better to pipe the file to ‘head’ so that we can get a clear view of it. This can be achieved by using the following command:
tcpdump -nn -r capture.pcap | head
The fields of the PCAP file would be in the following order:
1. Time
2. Network protocol
3. Source IP
4. Source Port
5. Destination IP
6. Destination Port
To concentrate on one of the above fields, remove some of them by using commands for piping and filtering. For example, the following command is used to get only the source IP address and its Port:
tcpdump -nn  -r capture.pcap | cut -f 3 -d “ “ | head
To filter the file to get TCP/IP and exclude the Layer 2 traffic, add the option ‘tcp’ or ‘udp’ at the end of the command:
tcpdump -nn  -r capture.pcap ‘tcp’ or ‘udp’ | cut -f 3 -d “ “ | head
To get only the IP address without the Port, just cut the other columns starting from “.”
tcpdump -nn -r capture.pcap ‘tcp’ or ‘udp’ | cut -f 3 -d “ “ | cut -f 1-4 -d “.” | head
2
Figure 2 : Using tcpdump to capture data
The ‘uniq’ command
The ‘uniq’ command can be used to remove repeated lines in the PCAP file, because we are not interested in the same source and destination twice. This command saves you a lot of time and avoids repetition:
tcpdump -nn -r capture.pcap ‘tcp or udp’  | cut -f 5 -d “ ” | cut - f 1-4 -d “.” | sort | uniq | head
The code below gives the top 10 destination IP addresses. ‘-nr’ gives the IP address in descending order:
tcpdump -nn -r capture.pcap ‘tcp or udp’  | cut -f 5 -d “ ” | cut - f 1-4 -d “.” | sort -c  | uniq -nr | head
3
Figure 3 : Count of packets
You can try every option available and get your work done easily.
Web tools
If you have a PCAP file you want to analyse but don’t have the tools or the sudo password to do so, try online tools such as Wireshark. I am using the small example file which was used for the challenge in picoCTF, where we need to find the destination of the ship from the conversation between the robot and the spaceship. This is a very easy challenge and can be addressed by having a clear look at the conversation (https://www.cloudshark.org/captures/bc1c0a7fae2c).
The alternatives for the cloud shark are given in the following urls.
http://www.wireshark.org/
http://canyouseeme.org/
http://www.lovemytool.com/
http://www.yougetsignal.com/
http://sectools.org/
You can try any of the tools from the above links. Some of them provide tools from the browser itself.
